Description
Technical Data
- Exhaust-air functionWith flow control option
- Type of actuationPneumatic
- Sealing principleSoft
- Mounting positionoptional
- Manual overrideNone
- DesignPiston gate valve
- Type of resetMechanical spring
- Type of pilotingDirect
- Flow directionNon-reversible
- Symbol00991513
- Valve function2/2-way, closed, monostable
- Operating pressure0.3 MPa … 1.6 MPa
- Operating pressure3 bar … 16 bar
- Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4] Inert gases
- Note on operating and pilot mediumLubricated operation possible (in which case lubricated operation will always be required)
- Corrosion resistance class CRC2 – Moderate corrosion stress
- LABS (PWIS) conformityVDMA24364-B1/B2-L
- Air purity class at outputCompressed air to ISO 8573-1:2010 [7:4:4] Inert gases
- Media temperature-10 °C … 60 °C
- Ambient temperature-10 °C … 60 °C
- Product weight126 g
- Type of mountingIn-line installation
- Note on materialsRoHS-compliant
- Material sealsNBR
- Material housingDie-cast aluminium
