Description
Technical specifications
| With optical interface |
False
|
|---|---|
| Supporting protocol for TCP/IP |
True
|
| Supporting protocol for DeviceNet |
False
|
| Supporting protocol for other bus systems |
False
|
| Redundancy |
True
|
| IO link master |
False
|
| Supporting protocol for DeviceNet Safety |
False
|
| Supporting protocol for EtherNet/IP |
True
|
| Power dissipation |
5.1 W
|
| Thermal dissipation |
17.4 btu/h
|
| Enclosure type rating |
None (open-style)
|
| Ethernet ports |
2 Ethernet RJ45 Category 5
|
| CIP unconnected messages |
128 + 128 (backplane + Ethernet)
|
| Current draw |
1A @ 5.1V DC, 3mA @ 24V DC
|
| Ethernet cable |
802.3 compliant shielded or unshielded twisted pair
|
| Wiring category |
2 – on Ethernet ports, 3 – on USB ports
|
| Communication rate |
10/100 Mbps
|
| Connections supported, max |
TCP: 128, CIP: 256 (CIP connections can be used for all explicit or all implicit applications. for exAle, a 1756-ENBT module has a total of 128 CIP connections that can be used for any combination of connections.)
|
| Isolation voltage |
30V (continuous), Basic Insulation Type, Ethernet to Backplane, USB to Backplane, and USB to Ethernet(Applies only to these modules/series: 1756-EN2T/D, 1756-EN2TR/C,1756-EN3TR/B), Type tested at 980V AC @ 60s
|
| Supporting protocol for LON |
False
|
| Supporting protocol for ASI |
False
|
| Supporting protocol for PROFIBUS |
False
|
| Supporting protocol for CAN |
False
|
| Supporting protocol for INTERBUS |
False
|
| Supporting protocol for KNX |
False
|
| Supporting protocol for Modbus |
False
|
| Supporting protocol for Data-Highway |
False
|
| Supporting protocol for SUCONET |
False
|
| With potential separation |
False
|
| Supporting protocol for SERCOS |
False
|
| Supporting protocol for INTERBUS-Safety |
False
|
| Radio standard Bluetooth |
False
|
| Radio standard Wi-Fi 802.11 |
False
|
| Supporting protocol for AS-Interface Safety at Work |
False
|
| Supporting protocol for Foundation Fieldbus |
False
|
| Supporting protocol for PROFINET CBA |
False
|
| Supporting protocol for PROFINET IO |
False
|
| Supporting protocol for PROFIsafe |
False
|
| Supporting protocol for SafetyBUS p |
False
|
| Radio standard GPRS |
False
|
| Radio standard GSM |
False
|
| Radio standard UMTS |
False
|
| Slot width |
1
|
| ATEX temp code |
T4
|
