Description
Technical specifications
| Nominal value output voltage 1 |
24 V
|
|---|---|
| Secondary voltage adjustable |
True
|
| Power output |
240 W
|
| Voltage type of supply voltage |
AC/DC
|
| Rated supply voltage at DC |
110 V
|
| Derating |
6 w/°c
|
| DC OK relay contact |
True
|
| Input inrush current limiter |
Active
|
| Output voltage |
24…28V DC
|
| Power factor |
0.92 typical
|
| Operational range |
88…188V DC
|
| Reserve power (typ. 4 s) |
15A @ 24V DC
|
| Rated output current |
9A @ 28V DC
|
| External input fuse, min |
B-6 A or C-4 A
|
| Power losses |
16.7 W typical
|
| Sub group |
Performance family
|
| Hold-up time |
27 ms
|
| Efficiency |
93.5% typical
|
| Input inrush current |
4 A/7 A
|
| Input voltage |
100…240V @ AC, 47…63 Hz
|
| Rated input current |
2.8A @ 100V AC
|
| Special feature |
Active PFC, Class 1 division 2, semi F47, 9) ABS/GL/RINA (marine)
|
| Output voltage stabilized |
True
|
| Rail mounting possible |
True
|
| Stabilized |
True
|
